Model NO.: SFB
-
Style: Screen-process Printing Press
-
Color & Page: Multi-Colour Printing Press
-
Print Interface: Screen Printing Machine
-
Color: Single Color,Two Color,Multicolor
-
Trademark: YIZHAN
-
Specification: CE, SGS
-
HS Code: 8443192100
-
Type: Oblique Arm Screen Printing Machine
-
Structure: Platen Press
-
Application: Packaging Printing
-
System Supported: Screen Printing Equipment
-
Print Area: 800*600mm/900*600mm/1200*600mm/1200*800mm
-
Transport Package: Standard Wooden Case
-
Origin: China, Zhejiang, Wenzhou
SFB Flat Screen Printing Machine

SFB flat screen printing machine (SERIGRAPHY) adopts manual feeding, the printing system is of line-contact running structure, and the scraper is actuated by air. The machine is controlled by PLC, the printing process is controlled by servo motor, and has manual, inching, continuous and other operating modes.
Features:
1. By servo motor control printing itinerary(high visغير مجاز مي باشدity ink for printing); Screen Printing equipment
2. Linnediately from the network struture and operation of synchronous scraper in the same time, not too demanding screen can get high precision printing;
3. Pneumatic locking net frame;
4. Unit allocation security protection devices;
5. Aluminum ramps arm.
Technical Parameter:
| Model |
SFB -8060A |
SFB -9060A |
SFB -12060A |
SFB -12080A |
| Max. printing dimensions |
800x600mm |
900x600mm |
1200x600mm |
1200x800mm |
| Max. dimensions of the frame(outside) |
1000x850mm |
1100x850mm |
1400x850mm |
1400x1100mm |
| Min dimension of the frame(outside) |
600x550mm |
700x550mm |
700x550mm |
700x800mm |
| Max. printing speed |
1200pcs/h |
1200pcs/h |
1100pcs/h |
1000pcs/h |
| Height of instant off-network |
0-25mm |
0-25mm |
0-25mm |
0-25mm |
| Use level of compressed air |
12L /min |
12L /min |
12L /min |
12L /min |
| Skewness of scraper |
0-30 ° |
0-30 ° |
0-30 ° |
0-30 ° |
| Air pressure |
0.4-0.6mpa |
0.4-0.6mpa |
0.4-0.6mpa |
0.4-0.6mpa |
| Weight |
550kg |
580kg |
620kg |
800kg |
| Printing thickness |
0 -50mm |
0 -50mm |
0 -50mm |
0 -50mm |
| Voltage power |
3P4N 50/60Hz 380v 2.2kw |
3P4N 50/60Hz 380v 2.2kw |
3P4N 50/60Hz 380v 3.2kw |
3P4N 50/60Hz 380v 3.2kw |
| Overall dimensions |
1570x1080x1450mm |
1570x1080x1450mm |
1570x1380x1450mm |
1850x1380x1450mm |
Sample:


FAQ:
Q1:We are interested in the screen printing machine,Could you quote the latest price to us?
A1: In order to recommend the suitable machine for you ,please provide following information before we quote price:
1.How many color to print will you need?
2.What's your max printing size? (Such as 500x700mm or biger or smaller)
3.What's the capacity per hour you request? (Such as 900pcs/h)
Q2:What's the MOQ, Delivery time, and payment terms?
A2: 1. MOQ: 1 set
2. Delivery time: 20 workdays after receiving T/T 30% payment deposit
3. Payment Term: T/T 30% as deposit, T/T 70% before shipment or L/C at sight
Our Service:
1. Warranty
1 year limited warranty after installation.If the spare parts is broken in the warranty
period , we will send a free replacement parts to you .
2. Installation and Training
We can send 1-2 engineers to buyers factory to install and set up the machines and
training, but all the charges for the engineers should be paid by buyer.
3. Quotation
The quotation is available in 60 days
