Deck Sheet Roll Forming Machine
-
Model NO.: AF-D700
-
Machine Color: According Your Requirment
-
Machine Weight: 15tons
-
Drive Type: Chain
-
Driven Type: Chain
-
Life Long: 10years
-
Transport Package: Normal
-
Origin: Shanghai
-
Name: Deck Sheet Roll Forming Machine
-
Machine Size: 12m*1.6m*1.6m
-
Size of Container: 40gp
-
Control System: PLC
-
Uغير مجاز مي باشدe: Roof and Wall
-
Trademark: Aofa
-
Specification: AF-D1025
-
HS Code: 84552210
Deck sheet roll forming machine
Deck floor roll forming machine
Other machine we manufacture
Cold roll forming mahcine, color steel roll forming machine, roof and wall panel machine, decking floor roll forming machine, floor decing forming mahcine, stud and track roll forming machine, Z and C purlin machine, highway guardrail roll forming machine, cable tray machine, and so on.
Working flow:
Decoiler-----feeding----- leveing and guiding ------roll forming ------cutting----output table
Machine Components:
De-coiler----------------------1 set
Forming machine------------1 set
Cutting device---------------1 set
PLC control box------------1 set
Hydraulic pump station----1 set
Production support table---1 set
Parameter
Technical description | |
Suitable material |
Color steel sheet , galvanized steel sheet, |
Main motor power |
15KW |
Hydraulic station power |
7.5KW |
Hydraulic oil |
36# |
Thickness of material |
0.7mm~1.2mm |
Diameter of principal axis |
Φ90mm |
Shaft material |
high grade No.45 steel after treatment |
Material expand width |
1000mm-1250mm |
Electric tension |
380V 3phase 50HZ |
Material of roller |
45# steel polished and coated with chrome HRC5 5 -60 ° |
Rolling galvanization thickness |
0.05mm |
Processing speed |
8-12m/min |
Processing precision within |
2.00mm |
Material of cutting blade |
Cr12 mould steel with quenched treatment |
Kind of drive |
1 inch chain |
Roller stations |
24 |
Control system |
PLC Frequency Control System with touch screen |
Service
Terms | |
Payment type | 35% T/T prepaid and balance should be paid before loading |
Delivery time | 30days after receving advance payment |
Guarantee period | 18monthes free service/ pay service all the machine life |
Installation and training | If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face. Without visiting, we will send you user manual and video to teach you to install and operate. If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things. |
MACHINE PHOTOS
Contact:
Abby Song
MOB: +86-18701854523
TEL: +86-21-67298619
Websites: http://shaofa.en.alibaba.com
http://www.shafjx.com
