Small Air Cooled Industrial Water Chiller
Model NO.: PCA series
Application Fields: Food Processing
Application Machine: Precision Machine Tool
Certification: ISO, CCC
Condition: New
Brand: U&C
Trademark: U&C
Transport Package: Standard
Origin: Zhejiang
HS Code: 8418692090
High Efficient Air-cooled Chiller/ Heat Pump
Operating Range:
Name | Cooling series | Heat Pump series |
Model | PCA 1067B~3510B | PCA1067BR~3510BR |
Cooling capacity | 236 to 1836 kw | 232 to 1800 kw |
Heating capacity | 264 to 2016kW |
Use :
The new generation of umbrellaclimate high efficiencywater chillers provides an optimal solution for all cooling applications in offices, healthcare facilities, industries, administration and commercial premises and collective housing.
These units are designed to be installed outdoors and do not require protection from adverse weather conditions.
This new range is optimised to run with the ozone-friendly HFC refrigerant?R410A?and thereby meet the most demanding environmental protection and high seasonal energy efficiency (ESEER) requirements.
Description :
R-410A refrigerant
Compact design and small footprint for outdoor installation
Two independent refrigerant circuits
Electronic expansion valves
New-generation, high-efficiency SCROLL compressors
All-aluminium?micro-channel high efficiencyair-cooled condenser
Propeller fan with optimised profile composite blades
EC type motor?with electronic pole switching and rotors with permanent magnets (standard on the HE series)
Electrical cabinet equipped with remote control transformer, safety switch, numbered wiring
Control module with Connect Touch microprocessor and a large range of auto adaptive functions
Interface with intuitive multilingual 4''3 colour touchsceen.
Communication with the CMS via the MODBUS/JBUS protocol as standard?
High reliable compressor
Strict quality testing
Siemens PLC controller
Cooling-Heating system
Make hot water for free!
Running environment temperature range
Cooling series:
Standard unit:0~43ºC
Low temp cooling:-20~43ºC
Heat pump series:
Standard cooling:0~43ºC
Standard heating:-10~21ºC Low temp cooling:-20~43ºC
Performance Data :
Model | PCA | 1050A | 1067A | 1078A | 1093A | 1108A | 1130A | 1153A | 1165A |
Cooling Capacity | kw | 176.1 | 235.4 | 271.3 | 324.4 | 371.7 | 451.1 | 532.3 | 582 |
Heating Capacity | kw | 193 | 273.1 | 314.7 | 376.3 | 431.2 | 523.3 | 617.7 | 675.1 |
Partial Heat Recovery Capacity | kw | 45 | 60 | 70 | 85 | 95 | 115 | 135 | 146 |
Power Supply | 380V/3N~/50Hz |
Gold Gravity Concentration Equipment
The STL water-jacketed Gold Concentrator is a kind of gravity separation equipment. It was developed by Changchun Gold Research Institute Co., Ltd. in 1985 and entered the market. At present, it has been used in many domestic and foreign companies. It is suitable for the recovery of single gold in placer gold, vein gold mines and polymetallic mines, instead of mercury plate operations. The addition of large single gold particles in the collected ore before flotation can further increase the recovery rate of gold mines, and it can also be used from gold-bearing mines. Separate single gold from flotation gold-copper concentrate and flotation gold concentrate.
The main indicators of this series of equipment basically reach the level of similar international products (such as Nielsen gold selectors, etc.). Compared with similar equipment at home and abroad, this series of equipment has the advantages of high غير مجاز مي باشدt performance, easy operation, and low maintenance غير مجاز مي باشدts.
Gold Gravity Concentration Equipment,Gold Separating Concentrator,Gold Recovery Centrifugal Concentrator,Centrifugal Gold Concentrator
Changchun Gold Research Institute Co.LTD , https://www.ccgrizb.com
