Printing Speed: Print Resolution (Dpi):Maximum 1, 440 Dpi
System Supported: Power Cord, Rip & Print Management Software
Width: Maximum 21.2 in (538 mm)
Printing Method: Piezo Ink-Jet Method
Power-Saving Function: Automatic Sleep Feature
Transport Package: Printer with Wooden
Specification: Maximum printing width/printing length:Maximum (20
Origin: Printer Made in Japan
Product Description
The LEF-200 offers countless product customization possibilities, including printing directly on three-dimensional objects up to 3.94" thick. Featuring a host of unique ink options and optional on-board Primer*, it quickly and effectively prints onto a wide variety of promotional products and media substrates.

Product Specification
Printing method |
Piezo ink-jet method |
Acceptable media |
Width |
Maximum 21.2 in (538 mm) |
Depth |
Maximum 14.2 in (360mm) |
Thickness |
Maximum 3.94 in (100mm) |
Weight |
Maximum 11 lbs (5kgs) |
Maximum printing width/printing length |
Maximum (20 x 13 in.) 508 x 330 mm |
Ink cartridges |
Type |
ECO-UV (EUV, EUV4) 220 cc cartridge |
Colors |
CMYKGlWh, CMYKPrWh, or CMYKWHWh |
Ink curing unit |
Built-in UV-LED lamp |
Print resolution (dpi) |
Maximum 1,440 dpi |
Distance accuracy (when printing) (*1) |
Error of less than ±0.3% of distance traveled, or ±0.3 mm, whichever is greater |
Connectivity |
Ethernet (10BASE-T/100BASE-TX, automatic switching) |
Power-saving function |
Automatic sleep feature |
Power requirements |
|
AC 100 to 240 V ±10%, 1.8 A (50 / 60 Hz) |
|
|
Power consumption |
During operation |
Approximately 149 W |
Sleep mode |
Approximately 13 W |
Acoustic noise level |
During operation |
60 dB (A) or less |
During standby |
49 dB (A) or less |
Outer Dimensions |
47.4 (width) x 37.9 (depth) x 21.7 (height) in.
(1,202 (width) x 962 (depth) x 549 (height) mm ) |
Weight |
242.5 lbs 110 kg |
Environment |
During operation (*2) |
Temperature: 68 to 90°F (20 to 32°C) (72°F / 22°C or higher is recommended) Humidity: 35 to 80% RH (no condensation) |
Not operating |
Temperature: 41 to 104°F (5 to 40°C) , Humidity: 20 to 80% RH (no condensation) |
Accessories |
Power cord, RIP & PRINT MANAGEMENT SOFTWARE (Roland VersaWorks Dual), user documentation, pad trays, etc. |

Features
Prep for Profitable Printing with On-Board Primer
The LEF-200 features an optional on-board primer* cartridge for priming objects quickly and conveniently on a selection of different media substrates. Users can easily prep an object for customization - printing Primer ink directly from a file in VersaWorks Dual RIP before printing the full-color graphic. This makes adding graphics to challenging materials much more clean and efficient.
Includes Roland VersaWorks Dual
The LEF-200 includes new VersaWorks Dual RIP software, featuring a new core engine for faster previewing times and improved handling of PDF and EPS files, including files with drop-shadows and transparencies.
In VersaWorks Dual there's no need to return to design software and you can set-up special color layers like White, Gloss and Primer directly in the RIP software. In addition, you can rotate, set spacing and Maintain Clip Position within the RIP to give you more control when printing graphics and applying Gloss Ink effects.
Roland VersaWorks Dual also offers a host of advanced features that include Predictive Ink Calculator, Spot Color Replacement, integrated Pantone® Spot Color Library and a Roland Texture System Library with a library of ready-to-use Gloss finishes and other effects.

Energy Efficiency
The LEF-200 uses an LED for UV-curing that last up to ten times longer than conventional UV lamps and can be instantly switched on or off, giving the user true on-demand production without the typical warm-up time. In addition, the LEF automatically enters a low-power mode when it is not used for an extended period of time.
Ink Flexibility, Efficiency and Consistency
Printing around the most complex corners and curves, advanced Roland ECO-UV® inks enable printing on a vast array of shapes and surfaces. The LEF-200 also features an Automated Ink Circulation System that prevents ink pigments settling in the ink lines
for consistently brilliant image quality with smooth consistency and density, even on long print runs.
Mist Filters
To ensure optimum print quality around the curvatures of objects, mist filters are incorporated in the LEF, catching the residual ink that mists when printing off the edge or curvature of a product. This cuts down on overspray and keeps the ink from settling on the printer's internal components. Filters are designed to be easily replaceable by the end user.
Rotaprint
Printing white and CMYK onto bottles and cylindrical objects is an absolute snap with the new RotaPrint attachment for the VersaUV LEF-200 flatbed printer. Simple to install and remove, it utilizes the LEF-200's existing feed system and enables the LEF to print cleanly and precisely onto a wide range of materials with a diameter between 1.6 to 3 inches (40 mm to 77 mm).
With its sturdy build, RotaPrint is also consistently and reliably accurate, ensuring precise stepping during rotation.

Applications
1.Print onto Objects with Curves and Contours
The LEF-200 prints around the complex curves and contours of an object. From trophies to keychains, it's the ideal machine for promotional item customization.
2.Souvenirs and Giftware
Print your designs onto wedding gifts, small souvenirs, earthenware, art frames and hundreds of other exciting giftware items. Finish them off with Gloss ink in matte or gloss for sophisticated embossed effects.
3.Awards and Trophy Customization
Take advantage of the LEF-200's optional on-board primer feature to easily add colorful logos, text, and designs to awards and plaques. Add an extra special touch with the elegance of Gloss ink embossed effects.
4.Electronic Items
With low-heat curing and non-magnetic printing, personalizing sensitive electronic devices like headphones, power banks, tablets and laptops is an absolute breeze.
5.Parts, Packaging and Products
Add graphics to packaging, models, toys, control panels and more and create production-quality product designs. For industrial items, variable data printing allows for individual serial number printing.
6.Signs and Larger Items
Print on coffee table tops, delicately crafted wood signs, canvas art and more. When you have an LEF-200, the possibilities are virtually limitless.

Superiority
1.Low MOQ:It can meet your sample display business very well.
2.OEM Accepted:The products can be customized
3.Good Service:No any excuses for 24 hours service
4.Good Quality:We have strict quality control system, good reputation in the market
5.Fast & Cheap Delivery:We have big discount from forwarder and aircargo (Long Contract)
Our Innovation
1.Quality & Service:At GETWIN, our priority has been providing our customers with great quality products and superior customer service with no excuses.
2.Quick Lead Time:We're dedicated to completing all orders in the fastest time with commitment.
3.Competitive Prices We continuously strive to find ways of reducing our production غير مجاز مي باشدts, and lower the purchase غير مجاز مي باشدt for you.
4.Brand Awareness:The goal of any strong brand is achieve a level of awareness that delivers the idea of quality, value, service and responsibility to all of your potential customers.
5.Special Offers:In order to maintain our competitive edge, we are running special offers on our promotional products, consumable parts and customized services.Please contact our sales team to see how we can help you save a lot of money.
Order Guide
1.Inquiry for professional quotation and patient communication.
2.Confirm the price, lead time, sample, payment term etc to complete orders.
3.WER sales send the PROFORMA INVOICE to you with GETWIN company seal.
4.Customer make the payment for deposit and send us The Bank Receipt.
5.Initial production will be arranged in terms of the lead time, we will inform customers in first time if any uncertain matters will happen, adjust the new lead time.
6.Middle Production will send photos to show production schedule which you can see your products in.Confirm everything goes well and let you relax.
7.End Production will send the photos to you for approval, we will arrange the shipment after approval You can also arrange the third party Inspection before shipment.
8.Clients make payment for balance and GETWIN sales will ship the goods.Also can accept
The Payment Term of Balance against B/L Copy Or Sight L/C payment Term.Inform the tracking number and check the status of parcel for clients or original B/L for sea-shipment.
9.Order can be say "finish" when you receive the goods and satisfy with them and our service.
10.Feedback about Quality & Service, Market Feedbacks & Suggestions, we can do better.
Excellent After-sale Services
1.One year warranty
You can discuss operation and maintenance with our technician online support service by Skype, MSN etc.Remote control will be provided upon request.
2.Free exchange of new components
Our quality is guaranteed 100%, the spare parts can be replaced within one year free of charge includes the airfreight by express, except for the print head and some damageable parts.
3.Free online consultation
The technician will keep online.No matter what kind of technical questions that you may have, you would get a satisfactory answer from our professional technician easily.
4.Free onsite installation and training
If you are able to help us with getting the visa and also would like to bear the غير مجاز مي باشدts involved like flight tickets, food, etc, we can send our technician to your office, and to give you a free installation and training for as long as you know how to operate it
Why choose GETWIN
A wide range of great products totaling over 50000 in future
.WER means customers can, employees can and investors can
.Professional customer after services and troubleshooting
.Become our potential partners as long as you believe yourself
.Friendly helpful customer services from GETWIN
.Free or low shipping غير مجاز مي باشدt from Shanghai port to any port
.No minimum order quantity request
.Shipping protected with product declaration

FAQ
1.What materials this printer can print on?
GETWIN eco solvent ink has a higher compatibility.A variety of professional print modes, meet the application requirements of different industries.Completely suitable for sublimation paper.
2.What is the printer production capacity / printing speed?
GETWINindoor sublimation printer equipped EPSON DX5 and DX7 Piezo print head, two printheads distributed Dislocated.The printing width of the printhead is 2 inch, each color has 720 nozzles, make the printing speed to increase 2 times, Auto sense ink supplying system, make the inks flow more smoothly, large front heating boards help to avoid drying inks to effect the ink output efficiency.Print 360*720 DPI,the speed can up to 52.7/hour.
3.What about the printing quality?
Equipped with EPSON DX5 and 5113 Piezo print head, variable drop printing, 1440 DPI high resolution output, unique two-dimensional eclosion function, eliminate the printing banding, improve the printing quality.Original import bushless motor, High precision drive, Linear decoding, higher accuracy, the length error is smaller, improve the printing quality, and ensure the stable running.
4.Is printhead easy to clog?
Use import ink stack, and automatic Print-head cleaning system,ink absorption, Moisturizing function, to get highest printing quality.Ensure the best printing output, The big capacity ink supplying system, guarantee the request of the ink supply.Improve the moisture of the nozzle.Ensure the output quality of the frame.
5.What software to be Compatible?
Intelligent design, compatible for maintop,photoprint etc printing software can be Compatible, scientific operation to make the printing easily.
6.Does the machine need long time to deal with the pictures?
Our printer equipped HI-USB, the transfer speed can be 480M/S, save much time for you.
7.Operating principle of thermal sublimation printer ?
Operating principle:Thermal sublimation transfer is based on the technology that some pigment
Will sublimate after heating to a certain degree.In the process of sublimation, pigment will dye
The fabric textile or synthetic material permanently after reaching on them.
When operating, firstly print the thermal sublimation ink to heat transfer paper.Graphics will be
Printed to the base materials after heating pressing.The design can be very clearly printed to the
Sublimation paper .
8.How to select the quality thermal sublimation ink?
1.Prints will be sublimated to products through the thermal sublimation of thermal sublimation ink, so rate of reduction of the ink color is very important.Very glad to sayimported thermal sublimation ink all have 90% rate of reduction, with which pictures have very good color saturation and are very bright.
2.If the thermal sublimation ink has big ink particle, it will clog the print head.Prints printed with it does not look very smooth.Sometimes can easily see particle with magnifying glass.
9.The applications of sublimation Eco Solvent printer.
The sublimation Eco solvent printer is widely used for printing textile, handbag, woven belt, luggage cases, gauze pad, packing materials, advertising media and so on.
