Circular Loom PP Woven Bag Making Machine (SL-SC-750/4)
-
Model NO.: SL-SC-4/750
-
Lines: 1
-
Speed: High
-
Layer: Double
-
Computerized: Computerized
-
Width: Can Be Customized
-
Factory Experience: More Than 20years
-
Transport Package: Suitable to Export
-
Origin: Wenzhou
-
Product Line: PP Woven Bag Making Machine
-
Voltage: 380V
-
Continuous-Rolled: Yes
-
Machine Type: Bag Forming Machine
-
Type: Plastic Bag Making Machine
-
Condition: New
-
Trademark: SL
-
Specification: ISO9001 and ISO14001
-
HS Code: 8446219000
Circular Loom PP Woven Bag Making Machine (SL-SC-750/4)
1. Circular loom
This machine was mainly used to take PP, PE plastic flat fibers to produce PP woven tubular fabric or liner film woven tubular fabric, and the cloth is widely applied in the production of fertilizer bags, grain bags, cement bags and feed bag.
2. Circular loom Main Feature
Plane cam and connecting rod rolling wheel transmission, which is the most advanced technology are adopted, making it easy and stable to run.
- Rolling transmission is adopted in entire structure instead of slide block and slide rod, which doesn't need lubricant and decreases the wearing part.
- It's an environmental product whose noise is not more than 82dB(A).
- Low strength plastic yarn which is made from 100% regenerated plastic can be adopted to weave.
- It is high-efficient and energy economical. The highest rotation speed of the main motor can reach 180r/min and the power is 1.5/2.2kw, which can save 10 thousand degree of electricity one year.
-As required, equipped with electronic intelligent fabric-lifting unit which is featured with the compensation setting to the warp/weft density casually.
- It is the latest type of circular loom
3.Main technical parameters
Shuttle | Four Shuttle |
Range of Diameter | 300-850mm |
Maxim Warps | 640/768pics |
Density of Warps | 32-58(pics/100mm) |
Speed of Main Engine | 140-180(r/min) |
Speed of Weaving | 1.4-1.8(m/min) |
Power of Main Engine | 1.5-2.2KW |
Specification of Bobbin | Φ38×230 Φ31×230 |
Maxim Diameter of Wefts Bobbin | Φ115mm |
Overall Dimension | 8300×2200×2730mm |
Weight | 1800kg |
Cam unit | adopt new-type plane cam structure, high output, high efficiency, low electricity consumption, low spare parts consumption. |
Shuttle unit | adopt ideal wheel form shuttle, non-lubrication, low pollution |
Cut of Warp | Stop Working Automatic and Identified by Conducting Light |
Uغير مجاز مي باشدe or Cut of Weft | Stop Working Automatic |
Counting Length Device | Micro computer Inspecting, Digit Display |
Control form of Main Engine | Frequency Conversion |
4. Advantage&Service
1. several senior engineers service in many countries, all the year round, with our after-sales office in countries.
2.Machines with quality guarantee for one year, life-long maintenance.
3.A lot of machines can be monitored via Internet, solve customer requirements immediately
4.Several senior engineers innovate and reform the technology continuous, in order to ensure the quality of mechanical
stability.
5.Undertake various non-standard machinery, solve the customers' special requirements
