Corrugated Sheet Line Wall Roof Panel Roll Forming Machine
Model NO.: WLFM18-76-988
Material: PPGI,PPGL,Pre-Painted Steel Sheet
Roller Material: 45#Steel with Chrome Treatment
Operation: Touch Screen and Button
Thickness: 0.3-0.7mm or 0.4-0.5mm
Yield Stress: 235-345 MPa
Max.Forming Speed: 12 M/Min
Total Motor Power: 7 Kw
Warranty: 12 Month
After-Sales Service Provided: Engineers Available to Service Machinery Overseas
Trademark: WILLING INT′L
Specification: CE Standard, ISO 9001-2008
Origin: China R. P
HS Code: 84552210
Corrugated Sheet Line Wall Roof Panel Roll Forming Machine With Mesh Security Cover
Components for the Machine:
The rollition driven forming stations, pressing die, cutting equipment, hydraulic station, PLC console and manual unload product run out table.
| Material specification | Aluminum, alu-zinc, galvanized and pre-painted galvanized steel. |
| Thickness |
0.3-0.7mm.(perfect is 0.4mm-0.6mm) |
| Main motor power | 4 |
| Hydraulic station power | 3kw. |
| Feeding width | 914/1000/1200mm. |
| Cover width |
WLFM 18-76-760/836/988 is 760/836/988mm respectively. |
| Yield stress |
235Mpa (33KSI) ~ 345Mpa (50KSI). |
| Roll forming Speed | 12 m/min |
| Cutting Tolerance |
+/-2.5mm(length≤5000mm); +/-3.0mm(5000mm<length≤10000mm). |
| Manual Uncoiler | Max. Capacity: 5000kgs. |
| Coil inner diameter |
508mm. |
| Voltage | 380V,3 Phase,50HZ,Or As per customer's request. |
| Numbers of stands | at least 17 stands/ stations |
| Type of cutting | Roll-formed and length-set profile cutting. |
3. Material of Main Equipment:
| Roller Material | High grade S45C forged steel, coated with hard chrome. |
| Active Shaft Material | High grade S45C carbon wrought steel, diameter 76mm. |
| Electric Elements | PLC control console, touch screen and transducer, from Siemens, Germany. Other elements, from Schneider Electric, Germany. |
| Cutter Blades | Cr12MoV steel with quenched treatment, hardness HRC58~61, wear-resistance, good steel structure, long life. |
Process Sketch
Uncoiling the sheet -Infeed guiding -Roll forming -Measure length - Cutting the panel - Panels to the supporter (option: automatic stacker).
Standard Equipment of Machine
| 1) | Manual Uncoiler | 1set |
| 2) | Infeed Guide | 1set |
| 3) | Roll Forming Station | 1set |
| 4) | Post-cut Equipment | 1set |
| 5) | Hydraulic Station | 1pc |
| 6) | PLC Control Console | 1pc |
| 7) | Product Support Table | 2pcs |
| 8) | Spare Parts | 1box |
Packaging & Shipping
1.One 40ft container for loading one set machine with manual decoiler;
2.The whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3.Spare parts and some small parts packed in plastic tooling box;
4.All Components Fixed by steel wire with Container.
FAQ
- Q:Are you a manufacturer?
- A:Yes absolutely. Welcome a lot for your visiting to us.
-
Q:What's the delivery time?
A:Normaly will take 60days
-
Q:Do you have after-sale support?
A:Yes, we're always here for giving you advice and support for technical details since we have senior technician.
-
Q:Is there quality control when manufacturing the lines?
A:Yes, we have a group of team who will be responsible for quality control from laying off the raw material, processing the rollers and the other parts, make treatment on the roller surface and shaft, assembling, testing and packaging.
-
Q:What's your strength comparing to the other supplier?
A:We'll supplying you the best quality and service. We'll give you good advise beyond your requirements. The lines are easily for installation and with low mantenance requirements.
