Good Double Deck Color Steel Roll Forming Machine
-
Model NO.: 975-875
-
Certification: CE, ISO, ISO9001: 2000, Ce, SGS
-
Customized: Customized
-
Transmission Method: Hydraulic Pressure
-
Suitable to Process: Color Steel Plate, Galvanized Board, Aluminum Plat
-
Warranty: 2year
-
Method: Roll Forming
-
Product: Tile
-
Automation: Automatic
-
Transport Package: Main Machine Is Nude
-
Origin: Cangzhou Hebei China
-
Tile Type: Colored Steel
-
Condition: New
-
Uغير مجاز مي باشدe: Roof, Wall
-
Color: as You Desire
-
Width of The Plate: 1000mm
-
Type: Single Deck Roof Sheet Roll Forming Machine
-
Processing: Roll Forming
-
Brick Raw Material: Color Steel
-
Trademark: XDL
-
Specification: 13*1.4*1.5
-
HS Code: 84552210
Brief introduction:
The roll forming machines can produce various of steel roof and wall panel, it is a new building materials, the products are widely used as the roof and wall of factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre, etc. It has many advantages, such as easy installation, short building period, beauty, light weight but high strength.
-
Unit Price, Quantity, Total Amount
| Name | Quantity(SET) |
Amount(USD) |
|
840-900 Double Deck Roof Roll Forming Machine |
1 |
10000 |
|
The quotation is valid for 15 days. The price will be based on other factors change (e.g. exchange rate). | ||
-
Packing Method
Main machine is nude, the computer control box is packed by carton box.
- Transportation
All machines need one 40 feet container to hold. If your company is not in China, We are in Tianjin port to delivery.
If you are located in China. Please tell me your shipping address, and select the mode of transportation.
- Payment Term
6.Delivery Time
Within 40 days after receiving deposit
- Warranty:
Our company used the brand parts about Schneider or Delta Electronics and so on, According to the customer need to choose.Easy to global sourcing. Overall easy loading and unloading machine. Customers can according to the need for replacement parts. And our company provide global service.
After we receive the deposit, our designer will arrange the producing of the machine. After assembling, we will debug the machine and at the same time, we will make video for the clients and teach them how to operate the machine. Before shipping, the machine is tested in our factory. when the client gets the machine, he can according to our video to operate the machine. If some parts of machine broken within 1 year, we will give him the spare parts for free. If more than 1 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect.
If you need, we can go to your place to assist you. But you need to provide the غير مجاز مي باشدt of the engineer.
If you can provide better drawings, we can produce machine for you.
| ||
| material spec |
colored steel sheet, galvanized steel sheet, aluminum sheet |
|
| thickness of coil sheet |
0.2-0.8 mm |
|
| material expand width | 1000mm | |
|
Efficiency width |
840 and 900mm |
|
| ||
| roller material | high grade NO. 45 forged steel with 0.05mm hard chrome plating | |
| shaft material | high grade NO. 45 carbon wrought steel | |
| cutting blade | Cr12 mould steel with quenched treatment | |
| diameter of shaft | 70mm or as your requirement | |
| main frame | 300 H steel | |
| forming steps |
Up layer:9 rows |
|
| productivity |
20-25m/min |
|
| hydraulic station power | 4 KW | |
| hydraulic pressure | 10-12MPa | |
| controlling system | famous PLC computer control | |
| material of cutting table | Cr 12 mould steel with quenched treatment | |
| appearance size |
6700mm*1500mm*1510mm |
|
| hydraulic oil | 40# hydraulic oil | |
| Electric tension | 380V 50 Hz 3 Phase or as your requirements | |
| ||
| Delivery | 30 workdays after receiving the deposit | |
|
Warranty |
one year warrantly and lifelong technical suport will be kind and |
|
|
Payments |
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment | |
-
Device Configuration
| No | number | |
| (1) | Manual decoiler | 1 set |
| (2) | Guiding device | 1 set |
| (3) | Main roll forming machine | 1 set |
| (4) | Hydraulic cutting device | 1 set |
| (5) | PLC electric control system | 1 set |
| (6) | Hydraulic driving system | 1 set |
| (7) | Special tools and parts | 1 set |
-
Equipment For Process Flow
Consist of Decoiler, Main roll forming machine, Cutting device, Hydraulic drive system, Electric control cabinet, ect.
-
Flow Chart
-
Detail Description
|
(1)Tension type decoiler |
Functional Configuration |
The worker put coil on the manual decoiler, and tensioning it through spanner. |
|||||||||||||||||||||||||||||||||||||||||||||||||
| technical parameters |
The maximum load capacity 5 Ton |
||||||||||||||||||||||||||||||||||||||||||||||||||
|
(2) Main machine system |
Roll forming system |
||||||||||||||||||||||||||||||||||||||||||||||||||
| X6-3020UV | ||
| Technical Specifications | ||
| Print Head |
RICHO GEN5 Print Head |
|
| Platform Size | 2000*3000mm | |
| Print Speed | 4pass 48sqm/hr | |
| 6pass 37sqm/hr | ||
| 8pass 27sqm/hr | ||
| Print Resolution | 720*1200dpi | |
| Ink Type | Environmental UV/LED Curable Ink | |
| Ink Capacity | 5000ml / Cartridge | |
| Ink Configuration | C,M,Y,K, Lc, Lm, W, V free combination | |
| File Format | TIFF, JPEG, Postscript, EPS, PDF, etc | |
| RIP Software | Maintop V6.0, Photoprint , ONYX, Caldera | |
| Media | Media Thickness | 1mm~100mm |
| Media Sort | Rigid and flexible sheet, like glass, ceramic tile, metal, wood, acrylic, PVC board, corrugated board, plastic, art paper etc. | |
| Electricity Request | Power: 4.3kw Requirements: AC 220V±10%, 50/60HZ |
|
| Operating Conditions |
Temperature:20-30C, |
|
| Printer Dimensions | H 1400mm * L 3930mm * W 3670mm | |
| Packing Dimensions | H 1500mm * L 4500mm * W 2300mm | |
| Net Weight | 1650kg | |
| Certification | CE, 3C | |
After sales service
1.12 months trouble-free warranty and online support for all of our machines.
2. Technical problems can be solved by detail description,photos or vedio
3. English Instruction book guide easily install ,operate and maintain the printer.
4. Lift - time maintance to ensure the normal operation.
5. All spare parts are available to replace the problem ones.
