Shanghai 100KV DC high voltage generator manufacturer
100KV DC High Voltage Generator Product Features:
◆ Small size, light weight, easy operation, complete functions, easy to use in the field, it is a new and modern ideal product.
◆ Using technology, process manufacturing, application of the latest PWM frequency pulse width modulation technology, pulse array logic array modulation, the use of high-power IGBT devices, the use of frequency conversion technology to increase the frequency, the frequency of 40kHz, so that the output high-pressure stability, the wavenumber coefficient is small.
◆ High precision and accurate measurement. The voltage and current are digital display. The voltage resolution is 0.1kv and the current resolution is 0.1uA. The voltage meter on the control box directly displays the voltage value added to the load test sample. No voltage divider is needed when using, and the wiring is simple. The instrument has high and low voltage side to measure leakage current, and the high voltage end adopts round shield digital meter display. It is not afraid of discharge shock and has good anti-interference performance. It is suitable for field use.
◆ High stability of voltage regulation, full range smooth voltage regulation, output voltage regulation of 100KV DC high voltage generator adopts imported single multi-turn potentiometer, stable step-up process, high adjustment accuracy, and a coarse and fine adjustment function. The voltage regulation is better than 0.1%, the voltage and current measurement error is less than 1.0%, and the ripple factor is better than 0.5%.
◆Polarity output, zero start, continuously adjustable, overvoltage, overcurrent, zero return, ground protection, unique breakage protection and other protection functions. The automatic protection circuit has strong functions, perfect and reliable protection, and makes operation safe. All kinds of technical indicators are better than the industry standard and better than similar products.
100KV DC High Voltage Generator Product Specifications:
◆ High-voltage output: 0-60KV0-120KV0-200KV0-300KV
◆ Current output: 0-2mA0-5mA0-10mA0-15mA

100KV DC High Voltage Generator Technical Performance:
Specifications
Technical Parameters
60/2-5
120/2-5
200/2-5
250/2-5
200/300
3/2
Other
Grade
Output voltage (kV)
60
120
200
250
200/300
600 ~ 800kV and other contracts
Custom made.
Output current (mA)
2-5
2-5
2-5
2-5
2-5
Output power (W)
120-300
240-600
400-1000
500-1250
600
Charging current (mA)
3.0
3.0
3.0
3.0
4.5/3.0
Chassis weight (kg)
4.3
4.3
4.4
4.5
8.1
Double cylinder height (mm)
Φ80
×500
Φ80
×770
Φ110
×770
Φ110
×820
Φ110
×1350
Double pressure weight (kg)
6.3
6.8
7.2
7.6
12.6
High voltage polarity
Negative polarity
Working power
220V±10%
Voltage measurement error
1% ± 1 byte
Current measurement error
1% ± 1 byte
Over-voltage setting error
≤ 1%
0.75 switching error
≤ 1%
Ripple factor
≤0.5%
Voltage stability
Random fluctuations. Supply voltage variation ±10%. ≤0.5%
Way of working
Discontinuous use: rated load 30 minutes; 1.1 times rated voltage uغير مجاز مي باشدe: 10 minutes
Ambient temperature
-15°C~50°C
Relative humidity
Not more than 90% when the temperature is 25°C (no condensation)
Altitude
2000 meters or less
